Double-face working table with honeycomb and aluminous strip is suitable for processing different kinds of materials. Automatical up and down working table, easy and friendly operation, it also can fix auto focus system to meet different processing demand.
Humanism designed system for top and bottom exhaust, ensure the safety of the processing, no need to worry about the entire process.
|
Suitable for double color plate,organic glass,glass,bamboo,paper,rubber,marble,granite,tile,and such non-metal material.
|
Laser type
|
Hermetic and detached CO2laser tube
|
Laser power
|
50W
|
Cutting area
|
600mm×400mm
|
No-load max speed
|
0-24000mm/min
|
Cutting table
|
Honeycomb strip panel double-face working table
|
Repeating location
|
±0.1mm
|
Automatic up & down distance
|
0-150mm
|
Moving system
|
5 inch LCD display, Offline stepping motor system,
|
Cooling system
|
Water cooling and protection system
|
Power supply
|
220V±5%/50Hz
|
Format support
|
AI,BMP,PLT,DXF,DST etc
|
Standard collocation
|
Mini air compressor, 550W down exhaust fan
|
Select collocation
|
CO2 RF metal laser tube,Rotary engraving system, red cross positioning system,constant temperature water chiller, servo system
|
FAQ
1. About us?
We are the true manufacturer, big factory, located at Jinan. About 5 minutes to Jinan Air port.
2. About price and quality?
We can not say we are the best supplier, but we are honesty for our quality and price. If you want to g
et cheapest machine, sorry we do not support you to buy. Good quality is our first rule. We produce
machines as 5S management rules, and ISO standard.
|
